Nested CV & Model Comparison¶

Fair Evaluation When You Also Tune Hyperparameters¶

Standard cross-validation gives an unbiased generalisation estimate — until you use the same CV loop to also select hyperparameters. Every time you pick the best alpha or the best kernel based on CV scores, you introduce an optimistic bias. Nested CV separates tuning from evaluation with two independent loops: the inner loop tunes, the outer loop measures.

The Problem with Non-Nested CV¶

Consider this workflow:

Try Ridge with alpha in {0.01, 0.1, 1, 10}.
Pick the alpha with the best 5-fold CV score.
Report that best CV score as your model’s performance.

The bias: step 2 selected the alpha that happened to do best on these folds. The reported score is the maximum over four candidates, not the expected score of a fresh model. The more hyperparameters you search, the more this inflates.

Demonstrating the Bias Empirically¶

%matplotlib inline
import numpy as np
import matplotlib.pyplot as plt
from sklearn.datasets import load_diabetes
from sklearn.linear_model import Ridge
from sklearn.preprocessing import StandardScaler
from sklearn.pipeline import make_pipeline
from sklearn.model_selection import GridSearchCV, KFold, cross_val_score

X, y = load_diabetes(return_X_y=True)
alphas = np.logspace(-3, 3, 20)
pipe   = make_pipeline(StandardScaler(), Ridge())

# Non-nested: pick best alpha by 5-fold, then report that same CV score
inner_cv = KFold(n_splits=5, shuffle=True, random_state=42)
gs = GridSearchCV(pipe, {'ridge__alpha': alphas}, cv=inner_cv,
                  scoring='r2', return_train_score=False)
gs.fit(X, y)
non_nested_score = gs.best_score_

# Nested: outer 5-fold wraps inner 3-fold GridSearch
outer_cv = KFold(n_splits=5, shuffle=True, random_state=0)
gs_nested = GridSearchCV(pipe, {'ridge__alpha': alphas},
                         cv=KFold(n_splits=3, shuffle=True, random_state=42),
                         scoring='r2')
nested_scores = cross_val_score(gs_nested, X, y, cv=outer_cv, scoring='r2')
nested_score  = nested_scores.mean()

print(f"Non-nested CV R²  : {non_nested_score:.4f}  (optimistically biased)")
print(f"Nested CV R²      : {nested_score:.4f} ± {nested_scores.std():.4f}  (unbiased)")
print(f"Optimism gap      : {non_nested_score - nested_score:.4f}")

fig, ax = plt.subplots(figsize=(7, 4))
ax.bar(['Non-nested\n(biased)', 'Nested\n(unbiased)'],
       [non_nested_score, nested_score],
       color=['tomato', 'steelblue'], width=0.4)
ax.errorbar([1], [nested_score], yerr=[nested_scores.std()],
            fmt='none', color='black', capsize=6, linewidth=2)
ax.set_ylabel('R²'); ax.set_title('Non-nested vs Nested CV on the diabetes dataset')
ax.set_ylim(0.3, 0.6)
plt.tight_layout(); plt.show()

How Nested CV Works — Step by Step¶

For outer $k_1$ -fold and inner $k_2$ -fold:

Split data into $k_1$ outer folds.
For each outer fold $i$ :
- Hold out fold $i$ as the outer test set.
- On the remaining $k_1 - 1$ folds, run inner $k_2$ -fold GridSearch to find the best hyperparameters.
- Refit the model with those best hyperparameters on all $k_1 - 1$ training folds.
- Evaluate on the held-out outer fold $i$ → get score $s_i$ .
Report $\bar{s} \pm \text{std}(s)$ .

Total fits = $k_1 \times k_2 \times |\text{param\_grid}|$ . For $k_1=5$ , $k_2=3$ , 10 alphas = 150 fits.

Nested CV From Scratch¶

import numpy as np
from sklearn.datasets import load_diabetes
from sklearn.linear_model import Ridge
from sklearn.preprocessing import StandardScaler
from sklearn.pipeline import make_pipeline
from sklearn.model_selection import KFold, cross_val_score

X, y = load_diabetes(return_X_y=True)
alphas = np.logspace(-2, 3, 10)

outer_cv = KFold(n_splits=5, shuffle=True, random_state=0)
inner_cv = KFold(n_splits=3, shuffle=True, random_state=42)

outer_scores = []
best_alphas  = []

for i, (outer_tr, outer_te) in enumerate(outer_cv.split(X)):
    X_out_tr, X_out_te = X[outer_tr], X[outer_te]
    y_out_tr, y_out_te = y[outer_tr], y[outer_te]

    # Inner loop: find best alpha on outer_tr
    best_score, best_alpha = -np.inf, None
    for alpha in alphas:
        pipe = make_pipeline(StandardScaler(), Ridge(alpha=alpha))
        inner_sc = cross_val_score(pipe, X_out_tr, y_out_tr,
                                   cv=inner_cv, scoring='r2')
        if inner_sc.mean() > best_score:
            best_score = inner_sc.mean()
            best_alpha = alpha

    # Refit best model on full outer train, evaluate on outer test
    pipe_best = make_pipeline(StandardScaler(), Ridge(alpha=best_alpha))
    pipe_best.fit(X_out_tr, y_out_tr)
    y_hat = pipe_best.predict(X_out_te)
    r2 = 1 - np.sum((y_out_te - y_hat)**2) / np.sum((y_out_te - y_out_te.mean())**2)
    outer_scores.append(r2)
    best_alphas.append(best_alpha)
    print(f"Outer fold {i+1}: best_alpha={best_alpha:.3g}  R²={r2:.4f}")

print(f"\nNested CV R²: {np.mean(outer_scores):.4f} ± {np.std(outer_scores):.4f}")
print(f"Best alphas per fold: {[f'{a:.3g}' for a in best_alphas]}")

Fair Model Comparison with Nested CV¶

%matplotlib inline
import numpy as np
import matplotlib.pyplot as plt
from sklearn.datasets import load_diabetes
from sklearn.linear_model import Ridge, Lasso
from sklearn.preprocessing import StandardScaler
from sklearn.pipeline import make_pipeline
from sklearn.model_selection import GridSearchCV, KFold, cross_val_score

X, y = load_diabetes(return_X_y=True)
alphas = np.logspace(-3, 3, 7)

outer_cv = KFold(n_splits=5, shuffle=True, random_state=42)
inner_cv = KFold(n_splits=3, shuffle=True, random_state=0)

def nested_cv_score(estimator_class, param_grid):
    pipe = make_pipeline(StandardScaler(), estimator_class())
    # Map param names with pipeline prefix
    prefix = estimator_class.__name__.lower()
    prefixed_grid = {f'{prefix}__{k}': v for k, v in param_grid.items()}
    gs = GridSearchCV(pipe, prefixed_grid, cv=inner_cv, scoring='r2')
    return cross_val_score(gs, X, y, cv=outer_cv, scoring='r2')

results = {}
results['Ridge']         = nested_cv_score(Ridge, {'alpha': alphas})
results['Lasso']         = nested_cv_score(Lasso, {'alpha': alphas})

# Bar chart with error bars
names  = list(results.keys())
means  = [results[n].mean() for n in names]
stds   = [results[n].std()  for n in names]
colors = ['steelblue', 'tomato']

fig, ax = plt.subplots(figsize=(8, 5))
bars = ax.bar(names, means, color=colors, alpha=0.8, width=0.5)
ax.errorbar(names, means, yerr=stds, fmt='none', color='black',
            capsize=6, linewidth=2)
ax.set_ylabel('Nested CV R²')
ax.set_title('Fair model comparison via nested CV\n(outer 5-fold / inner 3-fold)')
ax.set_ylim(0.3, 0.6)

for bar, m, s, n in zip(bars, means, stds, names):
    ax.text(bar.get_x() + bar.get_width()/2, m + s + 0.005,
            f'{m:.3f}±{s:.3f}', ha='center', fontsize=9)

plt.tight_layout(); plt.show()

print("\nFull results:")
for name in names:
    sc = results[name]
    print(f"  {name:<20} R² = {sc.mean():.4f} ± {sc.std():.4f}  per-fold: {np.round(sc, 3)}")

Statistical Testing — Is Model A Actually Better?¶

A difference in mean R² might just be noise. A paired t-test on the per-fold scores tests whether the difference is statistically significant.

import numpy as np
from scipy import stats

# Use scores from the comparison above
ridge_sc = results['Ridge']
lasso_sc = results['Lasso']

diff = ridge_sc - lasso_sc
t_stat, p_value = stats.ttest_rel(ridge_sc, lasso_sc)

print(f"Ridge mean R²  : {ridge_sc.mean():.4f}")
print(f"Lasso mean R²  : {lasso_sc.mean():.4f}")
print(f"Mean difference: {diff.mean():.4f} (Ridge - Lasso)")
print(f"Paired t-stat  : {t_stat:.4f}")
print(f"p-value        : {p_value:.4f}")
print()
if p_value < 0.05:
    winner = 'Ridge' if diff.mean() > 0 else 'Lasso'
    print(f"Conclusion: {winner} is significantly better (p < 0.05).")
else:
    print("Conclusion: No statistically significant difference between the two models (p >= 0.05).")
    print("The observed gap may be noise from the CV folds.")

When to Use Nested CV¶

Situation	Use nested CV?	Reason
Final model benchmarking for a paper or deployment decision	Yes	Keeps evaluation honest
Comparing two or more model families	Yes	Prevents biased selection
Quick prototyping during development	No	Too slow; use simple CV
Very large dataset ( $n > 100 000$ )	Rarely	Simple holdout usually sufficient
Small dataset ( $n < 200$ )	Yes	Extra folds extract more signal
Reporting to regulators or executives	Yes	Credibility requires rigour

Try It in the Browser¶

Manual 2-outer-fold, 3-inner-fold nested CV in pure Python.

Guided Practice¶

Why does non-nested CV give an optimistically biased performance estimate when hyperparameters are tuned?¶

The best hyperparameter is selected to maximise the CV score on those same folds, inflating the reported scoreCorrect. Every selection over a set of candidates uses the CV folds as a test set; the maximum is biased upward by chance variation.

The model trains on too little data per foldData size per fold is a bias-variance concern, not the source of the selection bias described here.

The inner and outer folds overlapIn standard GridSearchCV the folds do not overlap; the bias comes from using CV scores both to select and to report.

Ridge always overfits when alpha is smallOverfitting is a different issue from the selection bias in non-nested CV.

In nested CV, what does the inner loop do?¶

Evaluates the final model on unseen dataEvaluation is the job of the outer loop.

Selects the best hyperparameters on the outer training fold onlyCorrect. The inner loop runs GridSearch on the data left after the outer fold is held out.

Computes the final production predictionsNested CV is for evaluation; a separate final fit on all data produces production predictions.

Removes outliers from the training dataData cleaning is not part of the nested CV loop.

A paired t-test on nested CV fold scores returns p = 0.4. What should you conclude?¶

Model A is significantly better than Model Bp = 0.4 is well above the conventional 0.05 threshold for significance.

There is no statistically significant difference; the gap may be noiseCorrect. A high p-value means we cannot reject the null that both models perform equally.

Model B is better because the test failedFailing to reject the null does not favour either model.

You need to use a different datasetThe p-value does not imply the dataset is wrong.

With outer k=5, inner k=3, and a grid of 10 alpha values, how many model fits does nested CV run?¶

15That would be outer × inner only, ignoring the grid size.

50That would be outer × grid, ignoring the inner folds.

150 (5 × 3 × 10)Correct. Each of 5 outer folds runs a 3-fold grid search over 10 candidates = 150 fits total.

300300 would be correct if the outer loop also re-fitted the best model on the full outer train, but that extra fit is small in comparison.

Exercises¶

Exercise 1 — Quantify the bias gap on multiple datasets¶

import numpy as np
from sklearn.datasets import load_diabetes, load_boston
from sklearn.linear_model import Ridge
from sklearn.preprocessing import StandardScaler
from sklearn.pipeline import make_pipeline
from sklearn.model_selection import GridSearchCV, KFold, cross_val_score

alphas = np.logspace(-3, 3, 10)
pipe   = make_pipeline(StandardScaler(), Ridge())

X, y = load_diabetes(return_X_y=True)

# TODO: compute non_nested_score and nested_score for Ridge on diabetes
# Print the gap and interpret: is it large enough to matter for deployment decisions?

Exercise 2 — Three-model comparison with bar chart¶

Compare Ridge, Lasso, and a LinearRegression baseline using nested CV on the diabetes dataset. Plot a bar chart with error bars. Run a pairwise t-test between the two best models.

%matplotlib inline
import numpy as np, matplotlib.pyplot as plt
from sklearn.datasets import load_diabetes
from sklearn.linear_model import Ridge, Lasso, LinearRegression
from sklearn.preprocessing import StandardScaler
from sklearn.pipeline import make_pipeline
from sklearn.model_selection import GridSearchCV, KFold, cross_val_score
from scipy import stats

X, y = load_diabetes(return_X_y=True)
outer_cv = KFold(n_splits=5, shuffle=True, random_state=42)
inner_cv = KFold(n_splits=3, shuffle=True, random_state=0)
alphas   = np.logspace(-3, 3, 7)

# TODO:
# 1. Nested CV score for LinearRegression (no inner grid needed — use plain cross_val_score)
# 2. Nested CV score for Ridge (GridSearchCV inner + cross_val_score outer)
# 3. Nested CV score for Lasso (same)
# 4. Bar chart with error bars
# 5. Paired t-test between the two regularised models

Exercise 3 — Speed up with `n_jobs=-1`¶

Re-run the model comparison from the notebook cells above but pass n_jobs=-1 to both GridSearchCV and cross_val_score. Time both versions with %%timeit or time.time() and report the speedup factor.

import time
# Your code here

Common Pitfalls¶

Summary¶

Concept	One-line meaning
Selection bias	Picking the best CV score from a grid inflates the reported performance
Nested CV structure	Outer loop evaluates; inner loop tunes — they never share folds
sklearn pattern	`cross_val_score(GridSearchCV(pipe, grid, cv=inner_cv), X, y, cv=outer_cv)`
Cost	$k_1 \times k_2 \times
After nested CV	Refit final model on all data with best params — nested CV was for evaluation only
Statistical comparison	Paired t-test on outer fold scores — $p < 0.05$ to claim significance
When to use	Final benchmarks, comparing models, regulatory reporting

Next Up — Hyperparameter Tuning¶

You can now evaluate models fairly. Next: search for the best hyperparameters efficiently.¶

The next notebook — Hyperparameter Tuning — goes deeper into search strategies: grid search, random search, Bayesian optimisation, and early stopping. It shows how to set up a tuning pipeline that avoids leakage, scales to many parameters, and terminates efficiently.

Dependencies: nested CV structure, GridSearchCV / RandomizedSearchCV, and the principle that hyperparameter selection must not see the test fold.

Nested CV & Model Comparison¶

Fair Evaluation When You Also Tune Hyperparameters¶

The Problem with Non-Nested CV¶

Demonstrating the Bias Empirically¶

How Nested CV Works — Step by Step¶

Nested CV From Scratch¶

Fair Model Comparison with Nested CV¶

Statistical Testing — Is Model A Actually Better?¶

When to Use Nested CV¶

Try It in the Browser¶

Guided Practice¶

Why does non-nested CV give an optimistically biased performance estimate when hyperparameters are tuned?¶

In nested CV, what does the inner loop do?¶

A paired t-test on nested CV fold scores returns p = 0.4. What should you conclude?¶

With outer k=5, inner k=3, and a grid of 10 alpha values, how many model fits does nested CV run?¶

Exercises¶

Exercise 1 — Quantify the bias gap on multiple datasets¶

Exercise 2 — Three-model comparison with bar chart¶

Exercise 3 — Speed up with n_jobs=-1¶

Common Pitfalls¶

Summary¶

Next Up — Hyperparameter Tuning¶

You can now evaluate models fairly. Next: search for the best hyperparameters efficiently.¶

Exercise 3 — Speed up with `n_jobs=-1`¶
